Descripción
I.Main performance and structure features
1.Dual frequency conversion control, bag length can be set and cut in one step,saving time and film.
2.Interface features easy and quick setting and operation.
3.Self failure diagnosis,clear failure display.
4.High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5.Temperature independent PID control,more suitable for packaging different materials.
6.Positioned stop function,without sticking knife or wasting film.
7.Simple driving system,reliable working,convenient maintenance.
8.All control is realized through computer program,easy for function adjusting and technical upgrade.
II.Application
Suitable for packing regular objects such as biscuit,bread,instant noodle,moon cakes,industrial parts,paper box or trays.
III.Optional device
1.Code applying machine
2.line sealing wheel
3.Moire terminal sealing mould
4.Extra big screen
Specification
| Model | DCWB-250B | DCWB-250D | DCWB-250E | DCWB-250S | DCWB-32B | DCWB-320D |
| Film width | Max.250mm | Max.180mm | Max.320mm | |||
| Bag Length | 65-190mm or 120-280mm |
90-220mm | 50-115mm | 45-90mm | 65-190mm or 120-280mm |
90-220mm or150-330mm |
| Bag Width | 30-110mm | 30-80mm | 50-160mm | |||
| Product Height | Max.40mm | Max.55mm | Max.35mm | Max.40mm | Max.55mm | |
| Film roll Diameter | Max.320mm | |||||
| Packing Speed | 40-230bag/min | 60-330 bag/min | 40-230 bag/min | |||
| Power Supply | 220V,50/60HZ,2.4KW | 220V,50/60,2.4KW | 220V,50/60HZ,2.6KW | |||
| Machine Size | (L)3770*(W)670*(H)1450mm | (L)3770*(W)720*(H)1450mm | ||||
| Weight | About 700Kg | About 800Kg | ||||
| Remark | Gas filling device is optional | |||||
